2005 Bielomatik LVW-4822 vibration welder (05-12-51)
132# upper tool weight, 48″ x 22″ lift table & 35″ x 20″ weld head (with openings), 23.5″ daylight, Allen Bradley SLC5/05 PLC & Panelview 550 HMI, weld by distance, light curtains
+1 (651) 283-7444
Bielomatik
132#
63 amp
Bielomatik K-2250 hot plate welder, s/n – K2250/150
72” x 29” fixed lower platen
63” x 22” press platen (hydraulic)
50” x 22” rotating hot plate carrier
Siemens S7-300 PLC & OP27
new 2002, CE stamped
192#
Bielomatik K-3219 vibration welder, s/n – K-3219/16 (sold)
90 kg upper tool weight, 65 KW vibration drive, 64″ x 24″ hydraulic lift table, 51″ x 24″ vibration unit, 170-260 Hz frequency, Siemens S7-300 PLC & OP270 interface, CE stamped, 2006 (2)
192#
Bielomatik K-3219 vibration welder, s/n – K-3219/17
90 kg upper tool weight, 65 KW vibration drive, 64″ x 24″ hydraulic lift table, 51″ x 24″ vibration unit, Siemens S7-300 PLC & OP270 HMI, CE stamped, 2006
198#
Bielomatik K-3219-16 vibration welder, Siemens control
63” x 24” hydraulic lift table, 170-260 Hz, 90 Kg upper tool, 65 KW vibration drive, Siemens S7-300 PLC, 2006
396#
Bielomatik K-3220 vibration welder (sold)
74.8″ x 31.5″ lift table (rack & pinion), 90-130 Hz, 180 kg upper tool weight, 35 KW vibration drive, Allen Bradley SLC5/04 PLC & Panelview 1000 interface, 2002
396#
Bielomatik K-3220 vibration welder, low frequency, 2012
396# upper tool weight, 60″ x 24″ part size, 75″ x 31.5″ lift table with slide, 53″ x 15.75″ vibrating unit, Allen Bradley Compactlogix PLC & Panelview HMI
49" x 31.5"
Bielomatik K2252 infrared or hot plate welder, servos, 2017
49″ x 31″ horizontal tooling & slide, 28.6″ daylight, 800C max temp, infrared cameras, Siemens S7-300 controls, servos with rack & pinion, CE stamped, 40,690 cycles shown
396#
Bielomatik LVW-3225 vibration welder, 06-06-07
front to back vibration, 85-120 Hz, 396# upper tool weight, 2 mm amplitude, weld by distance, 75″ x 31″ lift table, 64″ x 20″ part size, AB SLC5/05 & Panelview 550, 2006
132#
Bielomatik LVW-4822 linear vibration welder, 02-09-55
54″ x 22″ lift table, 28.5″ vertical, 25 kN weld force, 85 sq inch weld plane, 35 KW drive, 132# upper tool, AB SLC5/05 PLC, Panelview 1000, light use, 2002 – SOLD
132#
Bielomatik LVW-4822 linear vibration welder, 03-07-33
132# upper tool weight, 54″ x 22″ hydraulic lift table, 28.5″ daylight, 35 KW vibration drive, laser measurement, AB SLC5/05 PLC & Panelview 1000, 2003, excellent
132#
Bielomatik LVW-4822 linear vibration welder, 04-05-14
132# upper tool weight, 54″ x 22″ lift table, 28.5″ vertical, 35 KW vibration drive, 25 kN weld force, AB SLC5/05 PLC, Panelview 1000, laser measurement, 2004, like new
132#
Bielomatik LVW-4822 vibration welder (02-05-26)
132# upper tool weight, 54” x 22” lift table, 23.5″ daylight, 35 KW Lenze drive, Allen Bradley SLC5/04 PLC, Panelview 1000 HMI, low cycle count, 2002
132#
Bielomatik LVW-4822 vibration welder, s/n 02-09-53 (sold)
54″ x 22″ hydraulic lift table, 28.5″ vertical clearance, 35 KW vibration drive, 132# upper tool weight, Allen Bradley SLC5/05 PLC, Panelview 1000, like new – 29 cycles
Bielomatik LVW-4822 weld head with springs
complete weld head for LVW-4822 or LVW-5422: (4) 14-7/8″ X 8-3/4″ X 1 springs (3) good springs (1) cracked spring driver coils new 2002
132#
Bielomatik LVW-5422 vibration welder, s/n – 02-05-28
54” x 22” lift table, 35 KW Lenze drive, Allen Bradley controls, 250,000 cycles, front/rear operator access, 2002
132# upper tool
Bielomatik LVW-5422 vibration welder, s/n – 02-05-30
54” x 22” lift table, 35 KW Lenze drive, Allen Bradley controls, 250,000 cycles, front/rear operator access, 2002
35 KW
Bielomatik LVW-5422 vibration welder, s/n – 02-05-30
54″ x 22″ hydraulic lift table, 35 KW Lenze vibration drive, front & rear operator access, Allen Bradley SLC5/04 PLC & Panelview 550 interface, 272,000 cycles, very clean, 2002
54" x 22"
Bielomatik tooling – adapter plates (2)
adapter plates allow mounting of standard Bielomatik tooling on non-standard lift tables
