This machine is no longer in stock. Let us know your requirements or if you have surplus.
50 – 450 cm2 weld plane
25 kN maximum clamp force
104″ x 27-1/2″ hydraulic lift table (rack & pinion)
54″ x 14″ vibration unit, has outboard supports
286# upper tool weight (198# nominal)
55″ vertical clearance (head is height adjustable)
31 kVA Branson Ultraschall vibration drive
80-120 Hz frequency range, manual & auto tune
.070″ – .160″ amplitude (1.8 – 4.0 mm)
Allen Bradley SLC5/04 PLC
32″ lift table stroke @ 8″/second
7-1/2 hp hydraulic pump (proportional)
111″ LR x 45″ H operator access, 32″ above floor
96″ x 96″ rear service doors, 2″ bottom channel
Quickpanel 10.5″ color touch screen interface
large enclosure, light curtain & finger actuator
20 second dry cycle time
579,000 cycles
new 2000, s/n – 00D400691
see video under power
